Name: Area 10 Profile

Display Field: UFID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="text-align:Justify;"><SPAN>The gravity main layer is a polyline feature class that contains information about the location and attributes of more than 5860 miles of sewer lines of the City of Houston’s sewer collection system. According to the City's Infrastructure Design Manual, a sewer line is a public sewer located within public Right-Of-Way or Permanent Access (PAE)/Public Utility Easement (PUE) that is maintained and operated by the City. The gravity main feature class includes LS Pump Line, Collector, Siphon, and Trunk. </SPAN></P><P><SPAN>The GIS Services Group of Houston Water, </SPAN><SPAN>Houston Public Works currently stores and maintains the dataset within a Relational Database Management System (RDBMS). </SPAN></P><P STYLE="text-align:Justify;"><SPAN>The data are derived from Plan and Profile Engineering drawings obtained from Block Map, As Built, Field Book, Taps and Meters, Metro, Autocad Data from GHW Project, Wastewater Reconciliation Project, Other Source (Operator Input), FVFL, FVFD, Field Verified with Control Number, and Construction Layer.</SPAN></P></DIV></DIV></DIV><DIV><P>This layer was last updated: 2023-02-20 01:00:35.666833.</P></DIV><DIV><P>This layer was last updated: 2023-05-19 16:40:37.720890.</P></DIV>

Copyright Text: City of Houston, Houston Public Works, Houston Water, GIS Services

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3136725.4193147123
YMin: 1.3822637721036151E7
XMax: 3138502.433149129
YMax: 1.382358032479398E7
Spatial Reference: 102740  (2278)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [155, 90, 68, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• UFID ( type: esriFieldTypeInteger, alias: UFID )
• INSERVICED ( type: esriFieldTypeDate, alias: In-service Date, length: 8 )
• PLAN_DATE ( type: esriFieldTypeDate, alias: Plan Date, length: 8 )
• REHAB_DATE ( type: esriFieldTypeDate, alias: Rehabilitation Date, length: 8 )
• SUBTYPE_CD ( type: esriFieldTypeInteger, alias: Subtype Code )
• US_INVERT ( type: esriFieldTypeDouble, alias: Upstream Invert Elevation )
• DS_INVERT ( type: esriFieldTypeDouble, alias: Downstream Invert Elevation )
• PC_SLOPE ( type: esriFieldTypeDouble, alias: Percent Slope )
• COMPKEY ( type: esriFieldTypeInteger, alias: COMPKEY )
• PLANNUMBER ( type: esriFieldTypeString, alias: Plan Number, length: 10 )
• REHABPLNUM ( type: esriFieldTypeString, alias: Rehab Plan Number, length: 10 )
• ILMS_NUM ( type: esriFieldTypeString, alias: ILMS Number, length: 15 )
• WCR_NUMBER ( type: esriFieldTypeString, alias: WCR Number, length: 20 )
• DS_MANHOLE ( type: esriFieldTypeString, alias: Downstream Manhole #, length: 25 )
• US_MANHOLE ( type: esriFieldTypeString, alias: Upstream Manhole #, length: 25 )
• ADDRESS_ID ( type: esriFieldTypeDouble, alias: Address ID )
• UNITID2 ( type: esriFieldTypeString, alias: Unit ID 2, length: 20 )
• UNIT_ID ( type: esriFieldTypeString, alias: UNITID, length: 20 )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 254 )
• LIFECYSTAT ( type: esriFieldTypeString, alias: Lifecycle Status, length: 254 )
• OWNER ( type: esriFieldTypeString, alias: Owner, length: 254 )
• PIPE_SHAPE ( type: esriFieldTypeString, alias: Pipe Shape, length: 254 )
• REHAB_MAT ( type: esriFieldTypeString, alias: Rehab Material, length: 254 )
• REHAB_METH ( type: esriFieldTypeString, alias: Rehab Method, length: 254 )
• REHAB_DIAM ( type: esriFieldTypeString, alias: Rehabilitated Diameter, length: 254 )
• REPLACE_YR ( type: esriFieldTypeString, alias: Replacement Year, length: 254 )
• PIPE_DIAM ( type: esriFieldTypeInteger, alias: Pipe Diameter )
• LONGITUDE ( type: esriFieldTypeDouble, alias: Longitude )
• LATITUDE ( type: esriFieldTypeDouble, alias: Latitude )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
