Name: Area 11 Existing Manholes

Display Field: LS_NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="text-align:Justify;"><SPAN>This geospatial layer is a point feature class that contains information about the location and attributes of manholes of the City of Houston’s wastewater collection system. The manhole feature class includes Diversion Box, Junction Box, and Manhole.</SPAN></P><P STYLE="text-align:Justify;"><SPAN>The GIS Services Group of Houston Water, Houston Public Works currently stores and maintains the dataset within a Relational Database Management System (RDBMS). </SPAN></P><P STYLE="text-align:Justify;"><SPAN>The data are derived from Plan and Profile Engineering drawings obtained from Block Map, As Built, Field Book, Taps and Meters, Metro, Autocad Data from GHW Project, Wastewater Reconciliation Project, Other Source (Operator Input), FVFL, FVFD, Field Verified with Control Number, and Construction Layer.</SPAN></P><P STYLE="text-align:Justify;"><SPAN /></P></DIV></DIV></DIV><DIV><P>This layer was last updated: 2023-04-10 08:07:19.856319.</P></DIV>

Copyright Text: City of Houston, Houston Public Works, Houston Water, GIS Services

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3067403.016621217
YMin: 1.381759473309064E7
XMax: 3157234.522981465
YMax: 1.3897408905154899E7
Spatial Reference: 102740  (2278)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [66, 170, 66, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ConsentDecree.HW.CDArea_11_Area11_RefManholes.FID ( type: esriFieldTypeString, alias: ConsentDecree.HW.CDArea_11_Area11_RefManholes.FID, length: 50 )
• UFID ( type: esriFieldTypeInteger, alias: UFID )
• INSERVICED ( type: esriFieldTypeDate, alias: In-service Date, length: 8 )
• PLAN_DATE ( type: esriFieldTypeDate, alias: Plan Date, length: 8 )
• REHAB_DATE ( type: esriFieldTypeDate, alias: Rehabilitation Date, length: 8 )
• MOTIONDATE ( type: esriFieldTypeDate, alias: Motion Date, length: 8 )
• PERMITDATE ( type: esriFieldTypeDate, alias: Permit Date, length: 8 )
• COVERSIZE ( type: esriFieldTypeString, alias: Cover Diameter, length: 255 )
• NOTE ( type: esriFieldTypeString, alias: Note, length: 255 )
• SUBTYPE_CD ( type: esriFieldTypeInteger, alias: Subtype Code )
• RIM_ELEV ( type: esriFieldTypeDouble, alias: Rim Elevation )
• BD_DEPTH ( type: esriFieldTypeDouble, alias: Buried Depth )
• FLOW_ELEV ( type: esriFieldTypeDouble, alias: Flow Elevation )
• INLETELEV1 ( type: esriFieldTypeDouble, alias: In Elevation )
• INLETELEV2 ( type: esriFieldTypeDouble, alias: In Elevation 2 )
• INLETELEV3 ( type: esriFieldTypeDouble, alias: In Elevation 3 )
• INLETELEV4 ( type: esriFieldTypeDouble, alias: In Elevation 4 )
• SUBDIVISON ( type: esriFieldTypeString, alias: Subdivision Name, length: 50 )
• DSDISTANCE ( type: esriFieldTypeDouble, alias: Distance To Downstream Manhole )
• COMPKEY ( type: esriFieldTypeInteger, alias: COMPKEY )
• CLEANTV_DT ( type: esriFieldTypeDate, alias: Clean TV Date, length: 8 )
• KEY_MAP ( type: esriFieldTypeString, alias: Key Map, length: 14 )
• IPS_FID ( type: esriFieldTypeString, alias: IPSFACILITYID, length: 11 )
• ADDRESS ( type: esriFieldTypeString, alias: Address, length: 100 )
• PLANNUMBER ( type: esriFieldTypeString, alias: Plan Number, length: 10 )
• REHABPLNUM ( type: esriFieldTypeString, alias: Rehab Plan Number, length: 10 )
• ILMS_NUM ( type: esriFieldTypeString, alias: ILMS Number, length: 15 )
• CONDITION ( type: esriFieldTypeString, alias: Condition, length: 20 )
• WCR_NUMBER ( type: esriFieldTypeString, alias: WCR Number, length: 20 )
• CTV_PJTNUM ( type: esriFieldTypeString, alias: Clean TV Project Number, length: 24 )
• PROJECTNUM ( type: esriFieldTypeString, alias: Project Number, length: 24 )
• REHAB_PNUM ( type: esriFieldTypeString, alias: Rehab Project Number, length: 24 )
• MH_NUMBER ( type: esriFieldTypeString, alias: Manhole Number, length: 25 )
• DATUM_YR ( type: esriFieldTypeString, alias: Datum Year, length: 4 )
• UNIT_ID ( type: esriFieldTypeString, alias: UNITID, length: 20 )
• IMSWONUM ( type: esriFieldTypeInteger, alias: IMS Work Order Number )
• SERVICE_AD ( type: esriFieldTypeString, alias: Service Address, length: 100 )
• SSO_VOLUME ( type: esriFieldTypeDouble, alias: Volume )
• ELEV_2018 ( type: esriFieldTypeDouble, alias: DEM Elevation 2018 )
• ELEV_2008 ( type: esriFieldTypeDouble, alias: DEM Elevation 2008 )
• LIFECYSTAT ( type: esriFieldTypeString, alias: Lifecycle Status, length: 255 )
• DS_DIRECT ( type: esriFieldTypeString, alias: Downstream Direction, length: 255 )
• CLEANTV_MT ( type: esriFieldTypeString, alias: Clean TV Method, length: 255 )
• DATUM ( type: esriFieldTypeString, alias: Datum, length: 255 )
• OWNER ( type: esriFieldTypeString, alias: Owner, length: 255 )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 255 )
• REHAB_MAT ( type: esriFieldTypeString, alias: Rehab Material, length: 255 )
• TYPE ( type: esriFieldTypeString, alias: Type, length: 255 )
• REHAB_METH ( type: esriFieldTypeString, alias: Rehab Method, length: 255 )
• REPLACE_YR ( type: esriFieldTypeString, alias: Replacement Year, length: 255 )
• SSOALERT ( type: esriFieldTypeString, alias: SSO Alert, length: 255 )
• METERBASIN ( type: esriFieldTypeString, alias: Meter Basin, length: 50 )
• LS_NAME ( type: esriFieldTypeString, alias: Lift Station Name, length: 254 )
• LS_FID ( type: esriFieldTypeInteger, alias: Lift Station ID )
• SERVICE_AR ( type: esriFieldTypeString, alias: Service Area, length: 50 )
• WWTP_FID ( type: esriFieldTypeString, alias: WWTP ID, length: 50 )
• SUBCATCH ( type: esriFieldTypeString, alias: Subcatchment, length: 30 )
• PLAN_AREA ( type: esriFieldTypeString, alias: Planning Area, length: 50 )
• SUBAREA ( type: esriFieldTypeString, alias: Sub Area, length: 50 )
• MAJOR_SYS ( type: esriFieldTypeString, alias: Major System, length: 50 )
• Flowmeter ( type: esriFieldTypeString, alias: Flowmeter ID, length: 25 )
• FLOODPLAIN ( type: esriFieldTypeString, alias: Flood Plain, length: 50 )
• WATERSHED ( type: esriFieldTypeString, alias: Water Shed, length: 50 )
• POND_DEPTH ( type: esriFieldTypeString, alias: Ponding Depth, length: 50 )
• COUNCIL ( type: esriFieldTypeString, alias: Council District, length: 254 )
• SUPERNEIGH ( type: esriFieldTypeString, alias: Super Neighborhood, length: 100 )
• WATERDISTR ( type: esriFieldTypeString, alias: Water District, length: 60 )
• TRACTGEOID ( type: esriFieldTypeString, alias: Census Tract ID, length: 11 )
• BLKGPGEOID ( type: esriFieldTypeString, alias: Census Block Group ID, length: 12 )
• BLOCKGEOID ( type: esriFieldTypeString, alias: Census Blocks ID, length: 16 )
• LONGITUDE ( type: esriFieldTypeDouble, alias: Longitude )
• LATITUDE ( type: esriFieldTypeDouble, alias: Latitude )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
