Name: All Pipe Parameters

Display Field: LS_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="text-align:Justify;"><SPAN>The gravity main layer is a polyline feature class that contains information about the location and attributes of more than 5860 miles of sewer lines of the City of Houston’s sewer collection system. According to the City's Infrastructure Design Manual, a sewer line is a public sewer located within public Right-Of-Way or Permanent Access (PAE)/Public Utility Easement (PUE) that is maintained and operated by the City. The gravity main feature class includes LS Pump Line, Collector, Siphon, and Trunk. </SPAN></P><P><SPAN>The GIS Services Group of Houston Water, </SPAN><SPAN>Houston Public Works currently stores and maintains the dataset within a Relational Database Management System (RDBMS). </SPAN></P><P STYLE="text-align:Justify;"><SPAN>The data are derived from Plan and Profile Engineering drawings obtained from Block Map, As Built, Field Book, Taps and Meters, Metro, Autocad Data from GHW Project, Wastewater Reconciliation Project, Other Source (Operator Input), FVFL, FVFD, Field Verified with Control Number, and Construction Layer.</SPAN></P></DIV></DIV></DIV><DIV><P>This layer was last updated: 2023-10-09 01:07:37.663342.</P></DIV>

Copyright Text: City of Houston, Houston Public Works, Houston Water, GIS Services

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3014649.203821972
YMin: 1.3762945270539388E7
XMax: 3211938.4663948864
YMax: 1.396609041805406E7
Spatial Reference: 102740  (2278)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [137, 35, 110, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• UFID ( type: esriFieldTypeInteger, alias: UFID )
• COMPKEY ( type: esriFieldTypeInteger, alias: COMPKEY )
• ILMS_NUM ( type: esriFieldTypeString, alias: ILMS Number, length: 15 )
• WCR_NUMBER ( type: esriFieldTypeString, alias: WCR Number, length: 20 )
• DS_MANHOLE ( type: esriFieldTypeString, alias: Downstream Manhole #, length: 25 )
• US_MANHOLE ( type: esriFieldTypeString, alias: Upstream Manhole #, length: 25 )
• ADDRESS_ID ( type: esriFieldTypeDouble, alias: Address ID )
• UNITID2 ( type: esriFieldTypeString, alias: Unit ID 2, length: 20 )
• UNIT_ID ( type: esriFieldTypeString, alias: UNITID, length: 20 )
• IMSWONUM ( type: esriFieldTypeInteger, alias: IMS Work Order Number )
• METERBASIN ( type: esriFieldTypeString, alias: Meter Basin, length: 50 )
• LS_NAME ( type: esriFieldTypeString, alias: Lift Station Name, length: 254 )
• LS_FID ( type: esriFieldTypeInteger, alias: Lift Station ID )
• SERVICE_AR ( type: esriFieldTypeString, alias: Service Area, length: 50 )
• SUBCATCH ( type: esriFieldTypeString, alias: Subcatchment, length: 30 )
• PLAN_AREA ( type: esriFieldTypeString, alias: Planning Area, length: 50 )
• SUBAREA ( type: esriFieldTypeString, alias: Sub Area, length: 50 )
• MAJOR_SYS ( type: esriFieldTypeString, alias: Major System, length: 50 )
• Flowmeter ( type: esriFieldTypeString, alias: Flowmeter ID, length: 25 )
• WATERSHED ( type: esriFieldTypeString, alias: Water Shed, length: 50 )
• COUNCIL ( type: esriFieldTypeString, alias: Council District, length: 254 )
• SUPERNEIGH ( type: esriFieldTypeString, alias: Super Neighborhood, length: 100 )
• WATERDISTR ( type: esriFieldTypeString, alias: Water District, length: 60 )
• LATITUDE ( type: esriFieldTypeDouble, alias: Latitude )
• LONGITUDE ( type: esriFieldTypeDouble, alias: Longitude )
• PIPE_DIAM ( type: esriFieldTypeSmallInteger, alias: Pipe Diameter )
• BASE_SIZE ( type: esriFieldTypeString, alias: Baseline Size, length: 255 )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 50 )
• IS_PLASTIC ( type: esriFieldTypeString, alias: Plastic Pipe Flag, length: 25 )
• INSERVICED ( type: esriFieldTypeDate, alias: In-service Date, length: 8 )
• PLAN_DATE ( type: esriFieldTypeDate, alias: Plan Date, length: 8 )
• BASE_AGE ( type: esriFieldTypeDate, alias: Baseline Sewer Age, length: 8 )
• SEWERAGE ( type: esriFieldTypeSmallInteger, alias: Sewerage )
• PIPE_AGE ( type: esriFieldTypeString, alias: Pipe Age, length: 100 )
• US_BDDEPTH ( type: esriFieldTypeDouble, alias: Upstream Buried Depth )
• DS_BDDEPTH ( type: esriFieldTypeDouble, alias: Downstream Buried Depth )
• PIPE_DEPTH ( type: esriFieldTypeDouble, alias: Pipe Depth )
• PDEPTH_CAT ( type: esriFieldTypeString, alias: Pipe Depth (Catagorized), length: 100 )
• SOURCE ( type: esriFieldTypeString, alias: Source, length: 255 )
• US_INVERT ( type: esriFieldTypeDouble, alias: Upstream Invert Elevation )
• DS_INVERT ( type: esriFieldTypeDouble, alias: Downstream Invert Elevation )
• PC_SLOPE ( type: esriFieldTypeDouble, alias: Percent Slope )
• STD_SLOPE ( type: esriFieldTypeDouble, alias: Standard Slope )
• DESIGNSLPC ( type: esriFieldTypeDouble, alias: Design Slope Difference )
• DESIGNSLOP ( type: esriFieldTypeString, alias: Design Slope, length: 255 )
• IS_BACKLOT ( type: esriFieldTypeString, alias: Backlot Sewer, length: 25 )
• IS_SIPHON ( type: esriFieldTypeString, alias: Siphon, length: 5 )
• ISUNDERSTR ( type: esriFieldTypeString, alias: Pipe Under Structure, length: 25 )
• IS_DIVERT ( type: esriFieldTypeString, alias: Diversionary Structure, length: 10 )
• ALLQUICKRT ( type: esriFieldTypeString, alias: Overall Quick Rating, length: 254 )
• STQQUICKRT ( type: esriFieldTypeString, alias: Structural Quick Rating, length: 254 )
• OMQUICKRT ( type: esriFieldTypeString, alias: O & M Quick Rating, length: 254 )
• PACP_SCORE ( type: esriFieldTypeDouble, alias: PACP Score )
• DEFECTCODE ( type: esriFieldTypeString, alias: Defect Codes, length: 254 )
• CLEAN_INTV ( type: esriFieldTypeInteger, alias: Cleaning Interval )
• LAST_CLEAN ( type: esriFieldTypeDate, alias: Last Cleaning Date, length: 8 )
• REHAB_DATE ( type: esriFieldTypeDate, alias: Rehabilitation Date, length: 8 )
• REHABPLNUM ( type: esriFieldTypeString, alias: Rehab Plan Number, length: 10 )
• REHAB_PNUM ( type: esriFieldTypeString, alias: Rehab Project Number, length: 24 )
• REHAB_MAT ( type: esriFieldTypeString, alias: Rehab Material, length: 255 )
• REHAB_METH ( type: esriFieldTypeString, alias: Rehab Method, length: 255 )
• REHAB_DIAM ( type: esriFieldTypeString, alias: Rehabilitated Diameter, length: 255 )
• EASE_XING ( type: esriFieldTypeString, alias: Easement Crossing, length: 25 )
• ROW_XING ( type: esriFieldTypeString, alias: ROW Crossing, length: 25 )
• ST_NAME ( type: esriFieldTypeString, alias: Street Name, length: 75 )
• SPEEDLIMIT ( type: esriFieldTypeInteger, alias: Speed Limit )
• LANES ( type: esriFieldTypeInteger, alias: Road Lanes )
• ROADCLASS ( type: esriFieldTypeString, alias: Road Class, length: 100 )
• ROADXING ( type: esriFieldTypeString, alias: Road Crossing, length: 25 )
• RAILROADX ( type: esriFieldTypeString, alias: Railroad Crossing, length: 25 )
• FLOODPLAIN ( type: esriFieldTypeString, alias: Flood Plain, length: 50 )
• POND_DEPTH ( type: esriFieldTypeString, alias: Ponding Depth, length: 50 )
• MUSYM ( type: esriFieldTypeString, alias: Mapunit Symbol, length: 6 )
• hydgrpdcd ( type: esriFieldTypeString, alias: Hydrologic Group, length: 254 )
• MINELV2008 ( type: esriFieldTypeDouble, alias: Minimum Elevation 2008 )
• MAXELV2008 ( type: esriFieldTypeDouble, alias: Maximum Elevation 2008 )
• AVGELV2008 ( type: esriFieldTypeDouble, alias: Average Elevation 2008 )
• USELEV2018 ( type: esriFieldTypeDouble, alias: Upstream LIDAR Elevation 2018 )
• USELEV2008 ( type: esriFieldTypeDouble, alias: Upstream LIDAR Elevation 2008 )
• DSELEV2018 ( type: esriFieldTypeDouble, alias: Downstream LIDAR Elevation 2018 )
• DSELEV2008 ( type: esriFieldTypeDouble, alias: Downstream LIDAR Elevation 2008 )
• SUBSIDENCE ( type: esriFieldTypeDouble, alias: Subsidence (ft) )
• NEAR_TREE ( type: esriFieldTypeString, alias: Trees Nearby, length: 25 )
• CAN_COVER ( type: esriFieldTypeString, alias: Canopy Coverage, length: 6 )
• DITCHXING ( type: esriFieldTypeString, alias: Ditch Crossing, length: 25 )
• CRIT_PROX ( type: esriFieldTypeDouble, alias: Critical Facility Distance )
• CRIT_FLAG ( type: esriFieldTypeString, alias: Critical Facility Flag, length: 10 )
• CRITFAC ( type: esriFieldTypeInteger, alias: Critical Facilities within 500ft )
• MFUNITPROX ( type: esriFieldTypeDouble, alias: Multi-Family Unit Distance )
• MFUNITFLAG ( type: esriFieldTypeString, alias: Multi-Family Unit Flag, length: 10 )
• MLTFAMUNIT ( type: esriFieldTypeInteger, alias: Multi-Family Parcels within 500ft )
• OFFICEPROX ( type: esriFieldTypeDouble, alias: Office Building Distance )
• OFFICEFLAG ( type: esriFieldTypeString, alias: Office Building Flag, length: 10 )
• OFFICEBLD ( type: esriFieldTypeInteger, alias: Office Buildings within 500ft )
• GREASEPARC ( type: esriFieldTypeString, alias: Grease Generator Parcel ID, length: 20 )
• DEV_AGE ( type: esriFieldTypeDouble, alias: Development Age )
• REDEV_AGE ( type: esriFieldTypeDouble, alias: Redevelopment Age )
• TRACTGEOID ( type: esriFieldTypeString, alias: Census Tract ID, length: 11 )
• BLKGPGEOID ( type: esriFieldTypeString, alias: Census Block Group ID, length: 12 )
• BLOCKGEOID ( type: esriFieldTypeString, alias: Census Blocks ID, length: 16 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• QUICKRATCD ( type: esriFieldTypeString, alias: Quick Rating Code, length: 25 )
• DITCH_DIST ( type: esriFieldTypeDouble, alias: Distance to Ditch )
• CHANNWIDTH ( type: esriFieldTypeDouble, alias: Channel Width )
• WTRBDYDIST ( type: esriFieldTypeDouble, alias: Distance to a Water Body )
• WATER_BODY ( type: esriFieldTypeString, alias: Water Body Name, length: 255 )
• WATERAREAA ( type: esriFieldTypeDouble, alias: Water Area (acres) )
• WATERBDYLN ( type: esriFieldTypeDouble, alias: Waterbody Length )
• STREAMDIST ( type: esriFieldTypeDouble, alias: Distance to Stream )
• LINEORIGIN ( type: esriFieldTypeString, alias: Line Origin, length: 31 )
• WATER_FEAT ( type: esriFieldTypeString, alias: Water Feature, length: 40 )
• WETLNDDIST ( type: esriFieldTypeDouble, alias: Distance to Wetland )
• WETLAND ( type: esriFieldTypeString, alias: Wetland Type, length: 50 )
• WETLANDAC ( type: esriFieldTypeDouble, alias: Wetland Area (Acres) )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
