Name: Force Main Condition Prediction

Display Field: LS_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="text-align:Justify;"><SPAN>This geospatial layer is a polyline feature class that contains information about the location and attributes of more than 320 miles of force mains of the City of Houston’s wastewater collection system. According to the City's Infrastructure Design Manual, a force main is a pressure-rated conduit which conveys wastewater from one pump station to one discharge point. This feature class includes force and sludge.</SPAN></P><P><SPAN>The GIS Services Group of Houston Water, </SPAN><SPAN>Houston Public Works currently stores and maintains the dataset within a Relational Database Management System (RDBMS). </SPAN></P><P STYLE="text-align:Justify;"><SPAN>The data are derived from Plan and Profile Engineering drawings obtained from Block Map, As Built, Field Book, Taps and Meters, Metro, Autocad Data from GHW Project, Wastewater Reconciliation Project, Other Source (Operator Input), FVFL, FVFD, Field Verified with Control Number, and Construction Layer.</SPAN></P><P /></DIV></DIV></DIV><DIV><P>This layer was last updated: 2024-05-28 14:55:19.523166.</P></DIV>

Copyright Text: City of Houston, Houston Public Works, Houston Water, GIS Services

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3018756.747116059
YMin: 1.3757369953277975E7
XMax: 3211897.449744642
YMax: 1.3963263333485141E7
Spatial Reference: 102740  (2278)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [50, 150, 168, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• UFID ( type: esriFieldTypeInteger, alias: UFID )
• INSERVICED ( type: esriFieldTypeDate, alias: In-service Date, length: 8 )
• PLAN_DATE ( type: esriFieldTypeDate, alias: Plan Date, length: 8 )
• REHAB_DATE ( type: esriFieldTypeDate, alias: Rehabilitation Date, length: 8 )
• US_INVERT ( type: esriFieldTypeDouble, alias: Upstream Invert Elevation )
• DS_INVERT ( type: esriFieldTypeDouble, alias: Downstream Invert Elevation )
• PC_SLOPE ( type: esriFieldTypeDouble, alias: Percent Slope )
• GRND_COVER ( type: esriFieldTypeDouble, alias: Ground Cover )
• LS_FID ( type: esriFieldTypeString, alias: Lift Station ID, length: 10 )
• COMPKEY ( type: esriFieldTypeInteger, alias: COMPKEY )
• PLANNUMBER ( type: esriFieldTypeString, alias: Plan Number, length: 10 )
• REHABPLNUM ( type: esriFieldTypeString, alias: Rehab Plan Number, length: 10 )
• ILMS_NUM ( type: esriFieldTypeString, alias: ILMS Number, length: 15 )
• WCR_NUMBER ( type: esriFieldTypeString, alias: WCR Number, length: 20 )
• PROJECTNUM ( type: esriFieldTypeString, alias: Project Number, length: 24 )
• REHAB_PNUM ( type: esriFieldTypeString, alias: Rehab Project Number, length: 24 )
• DS_MANHOLE ( type: esriFieldTypeString, alias: Downstream Manhole #, length: 25 )
• US_MANHOLE ( type: esriFieldTypeString, alias: Upstream Manhole #, length: 25 )
• UNITID2 ( type: esriFieldTypeString, alias: Unit ID 2, length: 20 )
• UNIT_ID ( type: esriFieldTypeString, alias: UNITID, length: 20 )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 255 )
• LS_DIRECT ( type: esriFieldTypeString, alias: LS Direction, length: 255 )
• OWNER ( type: esriFieldTypeString, alias: Owner, length: 255 )
• PIPE_SHAPE ( type: esriFieldTypeString, alias: Pipe Shape, length: 255 )
• REHAB_MAT ( type: esriFieldTypeString, alias: Rehab Material, length: 255 )
• REHAB_METH ( type: esriFieldTypeString, alias: Rehab Method, length: 255 )
• PIPE_DIAM ( type: esriFieldTypeSmallInteger, alias: Pipe Diameter )
• SUBTYPE_CD ( type: esriFieldTypeString, alias: Subtype Code, length: 25 )
• SERVICE_AR ( type: esriFieldTypeString, alias: Service Area, length: 50 )
• WATERSHED ( type: esriFieldTypeString, alias: Water Shed, length: 50 )
• FLOODPLAIN ( type: esriFieldTypeString, alias: Flood Plain, length: 50 )
• POND_DEPTH ( type: esriFieldTypeString, alias: Ponding Depth, length: 50 )
• COUNCIL ( type: esriFieldTypeString, alias: Council District, length: 254 )
• SUPERNEIGH ( type: esriFieldTypeString, alias: Super Neighborhood, length: 100 )
• WATERDISTR ( type: esriFieldTypeString, alias: Water District, length: 60 )
• TRACTGEOID ( type: esriFieldTypeString, alias: Census Tract ID, length: 11 )
• BLKGPGEOID ( type: esriFieldTypeString, alias: Census Block Group ID, length: 12 )
• BLOCKGEOID ( type: esriFieldTypeString, alias: Census Blocks ID, length: 16 )
• LSFIDSOURC ( type: esriFieldTypeString, alias: Lift Station FID Source, length: 100 )
• LS_FID_4 ( type: esriFieldTypeString, alias: Lift Station ID (4 Digit), length: 25 )
• LS_NAME ( type: esriFieldTypeString, alias: Lift Station Name, length: 1073741822 )
• LONGITUDE ( type: esriFieldTypeDouble, alias: Longitude )
• LATITUDE ( type: esriFieldTypeDouble, alias: Latitude )
• CONDIT_KPI ( type: esriFieldTypeInteger, alias: Condition (KPI) )
• Gr_RFO ( type: esriFieldTypeInteger, alias: Pipe Condition (Random Forest) )
• Prob_RFO ( type: esriFieldTypeDouble, alias: Failure Probability (Random Forest) )
• PREPACPCON ( type: esriFieldTypeInteger, alias: Predicted PACP Condition )
• Prob_XGB ( type: esriFieldTypeDouble, alias: Failure Probability (XG Boost) )
• Gr_LGB ( type: esriFieldTypeInteger, alias: Pipe Condition (Light GBM) )
• Prob_LGB ( type: esriFieldTypeDouble, alias: Failure Probability (LGBM) )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
